Primena:
- Za specijalna vozila za čišćenje kanalizacije pod visokim pritiskom
Prednosti:
- Veoma mala otpornost pri klizanju creva u bilo kakvoj cevi što omogućava efikasnije čišćenje, uštedu vremena i samim tim uštedu goriva
- Duži životni vek zahvaljujući specijalnoj mešavini gume u spoljnom omotaču creva visokootpornom na abraziju
- Veća fleksibilnost čak i pri veoma niskim temperaturama
- Lak za manipulisanje
- Otporan na deformacije i pojavljivanje klobuka usled prodora vazduha u medjuslojeve
- Veoma sigurno rukovanje zahvaljujući ojačanju od aramida (Kevlar)
Inner tube
SBR, black, smooth
Reinforcement
aramide textile, braided
Cover
SBR/NR, black, smooth. Very low sliding resistance
Temperature range
-30°C to +80°C.
Standard/Approval
ZH 1/406 (Guidelines for fluid spray jets).
Couplings/Fittings
All hoses are assembled with BSP female/BSP male. All assembled hoses are pressure tested at 375bar and have an unique hose number.
Complementary information
Delivered with test certificate on each factory assemblied hose.
Technical Specifications
| ID (mm) | Wall thickness (mm) | OD (mm) | Working pressure (bar) | Bursting pressure (bar) | Bending radius (mm) | Weight (kg/m) | Length (m) | Article number | Stock or min. order (m) |
|---|---|---|---|---|---|---|---|---|---|
|
13 ±0.5 |
6.3 ±0.5 |
25,6 |
250.0 |
625 |
70 |
0.45 |
40 |
5014178 |
• |
|
13 ±0.5 |
6.3 ±0.5 |
25,6 |
250.0 |
625 |
70 |
0.45 |
60 |
5014179 |
• |
|
13 ±0.5 |
6.3 ±0.5 |
25,6 |
250.0 |
625 |
70 |
0.45 |
80 |
5014180 |
• |
|
13 ±0.5 |
6.3 ±0.5 |
25,6 |
250.0 |
625 |
70 |
0.45 |
100 |
5014916 |
• |
|
13 ±0.5 |
6.3 ±0.5 |
25,6 |
250.0 |
625 |
70 |
0.45 |
120 |
5014005 |
• |
|
19 ±0.6 |
6.3 ±0.5 |
31,6 |
250.0 |
625 |
90 |
0.61 |
40 |
5014181 |
• |
|
19 ±0.6 |
6.3 ±0.5 |
31,6 |
250.0 |
625 |
90 |
0.61 |
80 |
5014182 |
• |
|
19 ±0.6 |
6.3 ±0.5 |
31,6 |
250.0 |
625 |
90 |
0.61 |
100 |
5014459 |
• |
|
19 ±0.6 |
6.3 ±0.5 |
31,6 |
250.0 |
625 |
90 |
0.61 |
120 |
5014006 |
• |
|
25 ±0.8 |
7.15 ±0.5 |
39,3 |
250.0 |
625 |
100 |
0.9 |
40 |
5014183 |
• |
|
25 ±0.8 |
7.15 ±0.5 |
39,3 |
250.0 |
625 |
100 |
0.9 |
50 |
5014874 |
• |
|
25 ±0.8 |
7.15 ±0.5 |
39,3 |
250.0 |
625 |
100 |
0.9 |
80 |
5014184 |
• |
|
25 ±0.8 |
7.15 ±0.5 |
39,3 |
250.0 |
625 |
100 |
0.9 |
100 |
5014238 |
• |
|
25 ±0.8 |
7.15 ±0.5 |
39,3 |
250.0 |
625 |
100 |
0.9 |
120 |
5014007 |
• |
|
25 ±0.8 |
7.15 ±0.5 |
39,3 |
250.0 |
625 |
100 |
0.9 |
150 |
5014461 |
• |
|
25 ±0.8 |
7.15 ±0.5 |
39,3 |
250.0 |
625 |
100 |
0.9 |
160 |
5014185 |
• |
|
25 ±0.8 |
7.15 ±0.5 |
39,3 |
250.0 |
625 |
100 |
0.9 |
180 |
5014186 |
• |
|
25 ±0.8 |
7.15 ±0.5 |
39,3 |
250.0 |
625 |
100 |
0.9 |
200 |
5014520 |
• |
|
25 ±0.8 |
7.15 ±0.5 |
39,3 |
250.0 |
625 |
100 |
0.9 |
200 |
5014520 |
• |
|
25 ±0.8 |
7.15 ±0.5 |
39,3 |
250.0 |
625 |
100 |
0.9 |
240 |
5014733 |
• |
|
32 ±1.0 |
7.8 ±0.6 |
47,6 |
250.0 |
625 |
130 |
1.12 |
40 |
5014187 |
• |
|
32 ±1.0 |
7.8 ±0.6 |
47,6 |
250.0 |
625 |
130 |
1.12 |
80 |
5014188 |
• |
|
32 ±1.0 |
7.8 ±0.6 |
47,6 |
250.0 |
625 |
130 |
1.12 |
120 |
5014008 |
• |
|
32 ±1.0 |
7.8 ±0.6 |
47,6 |
250.0 |
625 |
130 |
1.12 |
150 |
5014466 |
• |
|
32 ±1.0 |
7.8 ±0.6 |
47,6 |
250.0 |
625 |
130 |
1.12 |
160 |
5014189 |
• |
|
32 ±1.0 |
7.8 ±0.6 |
47,6 |
250.0 |
625 |
130 |
1.12 |
180 |
5014190 |
• |
|
32 ±1.0 |
7.8 ±0.6 |
47,6 |
250.0 |
625 |
130 |
1.12 |
200 |
5014655 |
400 |
|
38 ±1.0 |
8.0
|
54 |
250.0 |
500 |
155 |
1.35 |
120 |
5014009 |
• |
¤ Upon availability.
* Tolerance on length: ± 1 % (ISO 1307 Standard)
